UART2 available via 6 pin JST connector (EM-506 GPS style connector) UART0, UART1, UART5 available via 4 pin JST connectors

512MB DDR3800MHZ RAM (Integrated in the OSD3358)Īccess to USB1,Type A Socket, 500mA LS/FS/HS.

Cloud9 IDE on Node.js w/ BoneScript library.

GPS, DSM2 radio, UARTs, SPI, I2C, 1.8V analog, 3.3V GPIOs.

Easy connect interfaces for adding additional sensors such as:.User interface: 11 user programmable LEDs, 2 user programmable buttons.

Connectivity: HighSpeed USB 2.0 client and host.

Motor control: 8 6V servo out, 4 DC motor out, 4 quadrature encoder in.

Wireless: 802.11bgn, Bluetooth 4.1 and BLE.

Battery: 2-cell LiPo support with balancing, 9-18V charger input.

On-board 4GB 8-bit eMMC flash storage programmed with Debian Linux.

2×32-bit 200-MHz programmable real-time units (PRUs).

Processor: Octavo Systems OSD3358 1GHz ARM® Cortex-A8 Built on Octavo Systems’ System-In-Package that integrates a high-performance TI ARM processor and 512MB of DDR3, BeagleBone® Blue boots Linux in around 10 seconds and gets you started developing through your web browser in less than 5 minutes with just a single USB cable.

BEAGLE DRIVER SERIAL

BeagleBone® Blue has onboard 2 cell (2S) LiPo battery management with charger and battery level LEDs, 8 servo motor outputs, 4 DC motor drivers, 4 quadrature encoder inputs, a wide array of GPIO and serial protocol connectors including CAN, a 9 axis IMU and barometer, 4 ADC inputs, a PC USB interface, an USB 2.0 host port, a reset button, a power button, two user configurable buttons and six indicating LEDs. BeagleBone® Blue is based on the extremely successful open-source hardware design of BeagleBone® Black, a high-expansion, maker-focused, community-supported open hardware computer, created by the BeagleBoard.Org Foundation.īeagleBone® Blue combines the high-performance flexible WiFi/Bluetooth WiLink™ interface of the BeagleBone® Black Wireless and the robotics capabilities of the Robotics Cape from Strawson Design.
